sensor de temperatura para módulo fotovoltaico solar

The Solar Panel Temp Sensor uses a high-precision thermistor as the sensing component, featuring high measurement accuracy and stability, etc. The Solar Panel Temp Sensor uses an advanced circuit integration module that converts temperature into a corresponding voltage or current signal according to the user's different needs.

The Solar Panel Temp Sensor instrument is compact, easy to install and portable, with reliable performance.

The proprietary circuitry provides good linearity, high load capacity, long transmission distance and high immunity to interference.

The Solar Panel Temp Sensor can be used for a wide range of temperature measurement applications in meteorology, marine, environment, airports, ports, laboratories, industry, Photovoltaic solar energy,agriculture and transport.

Solar Panel Temp Sensor Technical Parameters：

Range: -50 to 100°C Optional -20 to 50°C

Accuracy: ±0.5℃

Power supply: DC 5V/DC 12V / DC 24V

Output type: 4～20mA /0～2.5V/0～5V /RS485

Instrument cable length: 5m

Load resistance: Voltage type: RL≥1K

Current type: RL≤250Ω

Operating temperature: -50℃～100℃

Relative humidity: 0～100%RH

Product weight: Probe 125 g

Product power consumption: 0.15W

Solar Panel Temp Sensor Instructions for use ：

1、At the centre of the back of the solar panel, use the heat-conductive silica gel sent with the package to coat an area with a size of approximately 22*12mm along the direction of the solar panel support.

2. Immediately after application, stick the Solar Panel Temp Sensor in the direction of the application and leave it fixed for about 5 to 10 minutes.

3. When the sensor is completely fixed on the back of the solar panel, first fix the Solar Panel Temp Sensor wire to the solar bracket along the solar panel alignment direction before proceeding with the normal alignment.

4. Users can fix the Solar Panel Temp Sensor according to the above method according to the actual usage environment.

With the rapid development of the photovoltaic power generation industry, temperature sensors have gradually become one of the indispensable key components in the photovoltaic system, and their wide application and precise control technology have become the focus of attention in the field of photovoltaic power generation.

Temperature sensor is a device that can measure the surrounding temperature. By sensing the temperature change on the surface of PV modules, it can reduce the power reduction of cells and improve the efficiency of PV power generation, while protecting PV modules from overheating or overcooling.
